The vacuum door lock is a feature of classic Mercedes vehicles, where the doors are locked by a vacuum pressure latching mechanism, and was prevalent in models from the 1970s to the early 2000s.

The lock system features components such as a vacuum pump, vacuum lines, actuators, connectors, and valves. The pump creates the vacuum pressure that locks and unlocks the latches of doors, fuel reservoir, trunk, and hood. The vacuum lines carry the pressure to the actuators. The actuators are the rubber-diaphragm-operated devices located inside the doors, trunk lid, and fuel filler door. When the vacuum pressure is applied to or released from the actuator, it moves the latching rod, locking or unlocking the doors.

Causes Behind The Failure of The Vacuum Door Lock in Mercedes

There are various points of malfunction in the vacuum door lock mechanism of Mercedes, and most of them are due to age-related damage.

• Over decades of exposure to engine bay heat and outside heat, the vacuum line gets brittle. With a slight impact, these brittle lines form cracks. As the lines carry vacuum pressure, even a fine crack will pull air and damage the functionality of the vacuum door locks.
• The actuator is a diaphragm made of rubber, which loses its elasticity over time. As a result, these become brittle and are prone to cracks and leaks. A faulty actuator is one of the most frequent causes of vacuum door malfunction.
• The vacuum pump that generates the vacuum pressure can malfunction, resulting in the failure of vacuum locks. Several malfunctions in the pump are: failure of the graphite impeller or burning out of the electric motor due to overuse.
• Valves and connectors play a crucial role in sealing various lines, ensuring the vacuum remains intact and the vacuum pressure is maintained. Corrosion and loosening of a seal expose its respective connector, allowing pressure to escape and creating a pathway for air to enter the vacuum lines.

The Mercedes shows various malfunction signs upon facing failures in the vacuum door lock mechanism. The initial or minor damages cause slow locking and unlocking of the vacuum doors. This also causes weak latching, where the locks are not appropriately put. An audible hissing sound is also a sign of a malfunction, which is caused by the inflow of air into the vacuum chamber through a very narrow passage.

The damage to the lock mechanism causes inefficient vacuum pressure generation, and to compensate for this, the pump runs longer than its normal duration of 2-3 seconds. Sometimes the pump runs for 15-20 seconds, indicating a sure malfunction. If only one door is malfunctioning, then the damage is isolated to the actuators and vacuum lines of that door or trunk.

The vacuum door failure poses a grave safety and security risk to both the driver and vehicle, as it exposes the vehicle’s cabin and interior to damage from outside.

Addressing The Vacuum Door Lock Failure in Mercedes

As the vacuum door is a feature of the classic Mercedes models, diagnostic scanners are useless for this issue. Several tests are performed to isolate the origin and cause of the problem, by eliminating various causes one after another.

A listening test is performed while operating the locks to identify the location that is causing the malfunction. If this test fails, the vacuum pump is located and isolated. Then, each line is individually tested for accurate feedback. The line that fails is the damaged one.

The repair process involves replacing the damaged component. For example, replacement of components like actuators, vacuum lines, and seals. Although the vacuum line can be repaired, considering the age and cost of the pump, replacement is a better option.
